Light Weight Lifepo4 Lithium Battery Cabinet Storage With Wheel 48V 400Ah 20KWH

Name: Light Weight Lifepo4 Lithium Battery Cabinet Storage With Wheel 48V 400Ah 20KWH
Brand: Hochiry
Price: 1 USD

Quality Light Weight Lifepo4 Lithium Battery Cabinet Storage With Wheel 48V 400Ah 20KWH wholesale

Brand Name : Hochiry

Certification : TUV

Place of Origin : CHINA

MOQ : 10PCS

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 10000 Piece per week

Delivery Time : 10-15 work days

Packaging Details : Product size: 23*12*20cm Manner of packing: Color Box Single weight:3kg QTY / Carton:4 unit / Carton Carton N.W.:15.4kg Carton G.W.:16.2kg Carton Size:49.5cm*46cm*21cm

Product name : Rechargeable 48v 100ah Battery

Battery Type : LiFePO4

Cycle life : 3000cycle/6000cycle

Protection : Built-in Smart BMS

Capacity : 50Ah/80ah/100Ah/200Ah

Application : Solar, Wind, UPS Energy Storage

Communication Port : RS232, RS485, CAN

Contact Now

Long Life Cycle LiFePO4 Batteries 5U 48V 200Ah Lithium Battery Pack Module

  	 			Specification
 			No. 			Item 			General Parameter 			Remark
 			1 			Combination method 			16S8P
 			2 			Rated Capacity 			400Ah 			Standard discharge after Standard charge(package)
 			3 			Factory Voltage 			51.2V 			Mean Operation Voltage
 			4 			Voltage at end of Discharge 			46V 			Mean Operation Voltage
 			5 			Charging Voltage 			58.4V
 			6 			Internal Impedance 			≤40mΩ 			Internal resistance measured at AC 1KH Z after 50% charge The measure must uses the
new batteries that within one week after shipment and cycles less than 5 times

 			7 			Standard charge 			Constant Current 100A 			Charge time : Approx 4.5h
 			Maximum Charge 			250A
 			8 			Standard discharge 			Constant current:100A
 			9 			Maximum Continuous
 			Discharge Current 			250A
 			10 			Maximum Discharge
 			Current 			40A
 			11 			Operation Temperature
 			Range 			Charge: 0~45℃ 			60±25%R.H.Bare Cell
 			Discharge: -20~55℃
 			12 			Storage Temperature
 			Range 			Less than 12 months : -10~35℃ 			60±25%R.H.at the shipment state
 			Less than 3 months: -10~45℃
 			Less than 7 day : -20~65℃
 			13 			Dimensions 			(L*W*H) 820*460*700mm 			Include case
 			14 			Weight 			250kg 			Include case

RDUCS DISPLAY

PRODUCT ADVANTAGE

APPLICATION

Energy Storage
--Solar-Wind Power System / City Grid (On/Off) / Community and Family
 Back-up System and UPS
 --Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment
 Other Applications
 --Security and Electronics / Mobile POS, Mining Lihgt / Torch / LED Light / Emergency Light
 --RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard
 --LED Backup / Engine Starting Battery,etc.

PACKING

 Good Quality Packs

 Low Quality Packs
SUPER SAFETY TEST

Passed the below abuse and safety test-short-circuit, dropping, nail penetration, impact, crush, thermal shock, over-charge,over-discharge: no fire, no explosion with stable chemical structure.

WHY CHOOSE US

◆ Experience--More than 12 years Specialized in lithium battery, Leaders of Lithium Lifepo4 Battery.
 ◆ Certification--CE,UL,MSDS,Test Report from National Center For Quality Supervision and Inspection of Battery Products approved.
 ◆ Quality Control-- 37 production process,7 steps quality check to promise stable quality and high reliability for you.
 ◆ Best Material-- Insist on choosing top quality cell, material and accessories,lithium battery last longer time.
 ◆ Fresh battery-- All battery is fresh Production.

Product Tags:

Wheel Lithium Battery Cabinet

Light Weight Lifepo4 Battery System 400Ah

Storage System Lifepo4 Lithium Battery Cabinet

Light Weight Lifepo4 Lithium Battery Cabinet Storage With Wheel 48V 400Ah 20KWH Images

Inquiry Cart 0

Send your message to this supplier


*From:	Your email address is incorrect!
*To:	SHENZHEN HODAS TECHNOLOGY COMPANY
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Specification
No.	Item	General Parameter	Remark
1	Combination method	16S8P
2	Rated Capacity	400Ah	Standard discharge after Standard charge(package)
3	Factory Voltage	51.2V	Mean Operation Voltage
4	Voltage at end of Discharge	46V	Mean Operation Voltage
5	Charging Voltage	58.4V
6	Internal Impedance	≤40mΩ	Internal resistance measured at AC 1KH Z after 50% charge The measure must uses the new batteries that within one week after shipment and cycles less than 5 times
7	Standard charge	Constant Current 100A	Charge time : Approx 4.5h
7	Maximum Charge	250A
8	Standard discharge	Constant current:100A
9	Maximum Continuous Discharge Current	250A
10	Maximum Discharge Current	40A
11	Operation Temperature Range	Charge: 0~45℃	60±25%R.H.Bare Cell
11	Operation Temperature Range	Discharge: -20~55℃	60±25%R.H.Bare Cell
12	Storage Temperature Range	Less than 12 months : -10~35℃	60±25%R.H.at the shipment state
		Less than 3 months: -10~45℃
		Less than 7 day : -20~65℃
13	Dimensions	(LWH) 820460700mm	Include case
14	Weight	250kg	Include case
