GJYXFCH G657A SM Fiber Optic Cable 1 Core FRP Strength Member 1200N

Brand Name : Hochiry

Model Number : FTTH Drop Cable Patch Cord

Certification : CE ROHS

Place of Origin : CHINA

MOQ : 100 Roll

Price : 0.07USD/Meter

Payment Terms : T/T, Western Union, MoneyGram

Delivery Time : 7-10 days

Packaging Details : 1000M per Wooden Roll

Fiber type : G652D ,G657A ,G657A2

Cable Structure : Self-support tight buffer

Strength member : FRP (Fiber glass reinforced plastic)

Installation tensile : 1200N

Fiber Amount : 1 fiber

Jacket : PVC LSZH PE

Contact Now

Ftth Flat Drop Indoor Outdoor Fiber Optic Cable G657A LSZH Fibra Optica Drop Cable

Description:

  • The optical fiber unit is positioned in the center.
  • Two parallel Fiber Reinforced Plastics (FRP) are placed at the twp sides.
  • Then the cable is completed with a black or white color LSZH sheath.

Features:

  • Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property
  • Two parallel strength members ensure good performance of crush resistance to protect the fiber
  • Simple structure, light weight and high practicability
  • Novel flute design, easily strip and splice, simplify the installation and maintenance
  • Low smoke, zero halogen and flame retardant sheath
  • Simple structure, light weight and high practicability

Application:

  • Used in indoor cabling, especially used for FTTH
  • Used as access building cable

Item
Technology parameter
Cable Type
Drop Cable
Cable Count
1 2 4 6 8 12
Fiber Color
Green, Yellow
Fiber Type
9/125 (G657A1)
Outer Sheath Color
Black or white
Sheath Material
LSZH
Cable Dimension (mm)
3.0(±0.1)*2.0(±0.1); 5.2(±0.1)*2.0(±0.1)
Cable weight (Kg/km)
15
Min. bending radius (mm)
10 (Static) 25 (Static) 30 (Static) 60 (Static)
Attenuation (dB/km)
≦ 0.4 at 1310nm, ≦ 0.3 at 1550nm
Short term tensile (N)
200; 600
Crush resistance (N/100mm)
1000; 2200
Operation temperature (℃)
-20~+70℃
Detailed Images
GJYXFCH G657A SM Fiber Optic Cable 1 Core FRP Strength Member 1200N

GJYXFCH G657A SM Fiber Optic Cable 1 Core FRP Strength Member 1200N
